Marine Bronze Angle Hose Valve JIS F7334B 5K/10K

[Search Related Products]

1. Marine Bronze Globe Hose Valve JIS F7334B 5K/10K (DN40-DN65) , 5K,10K available.

2. Materials:

(1)Body: Bronze BC6

(2). Disc: Bronze BC6

(3) Stem: Brass C3771BD

(4). Coupling: Bronze BC6

3. Size:


Code Size L Flange diam. (D) Pitch (C) Hole (nxd) Weight
(mm) (mm) (mm) (mm) (mm) (kgs)
751713 5K40 85 120 95 4XD15 5.91
751714 10K40 100 140 105 4XD19 8.19
751721 5K40 100 130 105 4XD15 11
751722 10K40 120 155 120 4XD19 14.3
751723 10K65 130 175 140 4XD19 23
4. Materials:
(1). Body: Bronze BC6
(2). Disc: Bronze BC6
(3). Stem: Brass C3771BD(4). Coupling: Bronze BC6
5. Size:
