Clamshell Bucket:
Clam shell bucket covers swing type and non-swing type . Non-swing type uses excavator bucket cylinder oil pathway£¬unnecessary to add hydraulic valve and pipeline£»Swing type needs to add one set of hydraulic valve and pipeline to control . Cylinders are with piston protective device .
Application£º
For digging holes of construction ground work£¬chasm digging and mud£¬sand£¬coal£¬gravel loading .
Especially for digging and loading of channel or one side of limited space .
Loading and unloading vessels£¬trains£¬cars .
|
Technical Parameters£º
|
|
Machine Tonnage
|
Description
|
numbEr of tine
|
Weight(Kg)
|
Material
|
|
3-5T
|
Non-swingClam shell Bucket
SwingClam shell Bucket
|
4
|
380
420
|
Q345B+NM360
Q345B+NM360
|
|
6-10T
|
Non-swingClam shell Bucket
SwingClam shell Bucket
|
4
|
570
620
|
Q345B+NM360
Q345B+NM360
|
|
11-16T
|
Non-swingClam shell Bucket
SwingClam shell Bucket
|
5
|
820
880
|
Q345B+NM360
Q345B+NM360
|
|
17-20T
|
Non-swingClam shell Bucket
SwingClam shell Bucket
|
5
|
1080
1180
|
Q345B+NM360
Q345B+NM360
|
|
21-24T
|
Non-swingClam shell Bucket
SwingClam shell Bucket
|
5
|
1200
1300
|
Q345B+NM360
Q345B+NM360
|
|
25T30T
|
Non-swingClam shell Bucket
SwingClam shell Bucket
|
6
|
1320
1450
|
Q345B+NM360
Q345B+NM360
|
|
31-35T
|
Non-swingClam shell Bucket
SwingClam shell Bucket
|
6
|
1450
1600
|
Q345B+NM360
Q345B+NM360
|
|
36-40T
|
Non-swingClam shell Bucket
SwingClam shell Bucket
|
6
|
1680
1850
|
Q345B+NM360
Q345B+NM360
|
|
41-45T
|
Non-swingClam shell Bucket
SwingClam shell Bucket
|
6
|
1950
2150
|
Q345B+NM360
Q345B+NM360
|
|
