Marine Cast Steel Gate Valve CB/T466-1995

Marine Cast Steel Gate Valve CB/T466-1995:

1.Design standard:CB/T466-1995.

2.End standard:GB/T2501 &GB/T569.

3.End type Flange.

4.PN:0.25/0.4/0.6/1.0Mpa.

5.DN:

  • PN 1.0Mpa:50mm-100mm;
  • PN 0.6Mpa:125mm-150mm;
  • PN 0.4Mpa:175mm-300mm;
  • PN 0.25Mpa:350mm-500mm.

6.Main material:

  • Body/Bonnet:ZG230-450;
  • Seat:SS410/BC6;
  • Stem:SS410/BS;
  • Disc:FC20/FCD450.

7.Application:Sea water piping,fresh water piping and oil piping.

8.Function:Such valves are used for on-off duty.

9.Fundamental dimensions of Marine Cast Steel Gate Valve CB/T466-1995(Type A):

PN

Mpa

DN

mm

Structure dimension

Flange

Bolt

Stem

Hand

wheel

D0

Lift

range

m

Weight

kg

L

H

D

D1

D2

b

d0

n

Th.

d

1.0

50

190

340

135

103

84

13

15

6

M14

Tr22x10(P5)LH

14

180

60

18

65

200

372

155

123

104

14

15

6

M14

Tr22x10(P5)LH

14

180

75

20

80

220

430

170

138

118

14

15

8

M14

Tr24x10(P5)LH

17

200

92

25

100

220

460

190

158

138

14

15

8

M14

Tr24x10(P5)LH

17

200

112

28

0.6

125

242

528

215

183

164

14

15

10

M14

Tr26x10(P5)LH

19

225

138

41

150

248

566

240

208

190

14

15

12

M14

Tr26x10(P5)LH

19

225

165

51

0.4

175

268

630

270

238

221

15

15

12

M14

Tr28x10(P5)LH

22

250

190

70

200

278

685

295

264

247

15

15

12

M14

Tr28x10(P5)LH

22

250

215

80

250

310

755

365

327

306

16

17

14

M16

Tr30x10(P6)LH

24

280

265

111

300

345

835

430

386

360

19

21

14

M20

Tr30x10(P6)LH

24

280

315

134

0.25

350

400

954

480

436

410

20

21

16

M20

Tr36x10(P6)LH

27

320

365

219

400

430

1045

530

486

460

21

21

16

M20

Tr36x10(P6)LH

27

360

418

267

450

460

1228

580

536

512

21

21

18

M20

Tr40x10(P6)LH

32

400

421

395

500

480

1315

635

591

567

21

21

20

M20

Tr40x10(P6)LH

32

450

518

519

10.Drawing of Marine Cast Steel Gate Valve CB/T466-1995:
