EU Type Bulwark Mounted Chock

Technical information mooring chock

Can be called 'bulwark chock', is located in the bulwarks, with closed hole shaped fairlead limit position of the cable are derived. Its basic shape is circular, oval

The mooring chock is a very important mooring equipment. In the process of mooring ship, it bears huge loads. Usually the ship bollards, mooring chock for the whole ship mooring use. The general bow and stern ofship blocks the bollard fairlead, quantity large. Of intermediate section above without or bollards, fairlead rarely.Fairlead is oblique chock more insurance, because it is closed, the cable will not jump out .

EU Type Bulwark Mouting Chock

Specifications

Nominal Size(mm)	Dimension(mm)							Weight (kg)
Nominal Size(mm)	L	H	L2	H2	H1	B	L1	Weight (kg)
315x250	315	250	695	630	432	342	497	198
425x280	425	280	925	780	515	450	661	358
600x315	600	315	1160	875	571	504	866	547
600x450	600	450	1160	1010	706	504	856	850
800x600	800	600	1500	1300	860	580	1060	1200
1000x800	1000	800	1760	1560	1250	700	1450	1580

Mooring Chock

Mooring Chock

EU Type Bulwark Mounted Chock
