High Power Remote-controlled LED Marine Lantern

High Power Remote-controlled LED Marine Lantern

1. Nominal range up to 18 nautical miles;

2. Fixed light intensity up to 50000cd;

3. Light range 18nm (T=0.74,white light)

4. Built-in GPS synchronization module, can realize multi-lamp wireless synchronous flash;

5. Built-in GSM/VHF communication module (RTU), can be used as remote monitoring terminal

Technical Parameters

Model	HS-L500A
Woking Voltage	24V DC
Daylight Switch	300Lux±50Lux
Characteristics of Light	IALA256
Consumption Power	180W 10 layers (when the lamp is bright)
Divergence Angle	2.5°(in accordance with IALA standard)
Horizontal Distribution Uniformity	＞90%
Communication Serial Port	RS232/RS485(optional)
Light Color	Red, Green, White(optional)
Lens Material	Anti UV organic glass
Chassis Material	Marine grade alluminum alloy
Working Temperature	-30℃~+70℃
Relative Humidity	100%(condensation)
Protection Grade	IP68
Cooling Mode	Air Cooling
