Marine Bilge Water Separator

The marine bilge water separator is used to treat the vessel bilge water, making the discharges meet the requirements of IMO.MEPC.107 (49) resolution.

It also called 15ppm oil water separator, or oil water separator plant.

Our YWC series bilge water separator adopts:

1st stage: cone plate gravity and coalesce separation;

2nd stage: fiber filter;

3rd stage: membrane permeation.

Marine Bilge Water Separator

Certificate: CCS, EC, BV, GL approvable.

Marine Bilge Water Separator

Technical Data:

Model

YWC-

Technical Specifications

0.25

0.5

1

1.5

2

2.5

3

4

5

Rated capacity(m3/h)

0.25

0.5

1

1.5

2

2.5

3

4

5

Oil content of the discharged water

°Ř15ppm

Power of the electric heater£®kw£©

1kw

3kw

6

6

6

6

6

12

12

Electrical System

AC 380V/50Hz/3¶’,AC 415V/50Hz/3¶’,AC 440/60Hz/3¶’,AC 480V/60HZ/3¶’(optional)

Power of the electric motor

0.37kw

0.55kw

0.75kw

1.1kw

1.1kw

1.5kw

1.5kw

2.2kw

2.2kw

Suction head

°Ř6m-H2O

Pressure of the discharged water

5-10m-H2O

Outline Dimension£®L*W*H£©(mm)

1000*600

*1250

1100*690

*1460

1050*1000

*1620

1100*1130

*1650

1900*1120

*1700

1900*1120

*1900

1700*1500

*1900

2280*1700

*1900

2590*2000

*1900

Base

5#

6#

6#

6#

8#

8#

8#

10#

10#

Weight

Dry Weight

400

600

800

1060

1260

1500

1800

2100

2500

Wet Weight

550

900

1200

1650

2260

2800

3200

3900

4600

Applicable Vessel (KDWT)

<1

1-5

5-10

10-30

30-50

50-100

100-200

100-300

>300
