0.50m3/h Rated Capacity Marine Oil Water Separator

This device can be used to treat oily bilge water in order to make it reach the requirements of IMO.MEPC.107 (49) resolution, which is also called 15ppm bilge separator.

It contains type approved 15ppm bilge water separator, 15ppm bilge alarm and automatic shut down Device.

Technical Specification:

Type: YWC-0.50
Rated capacity: 0.50 m3/h
Effluent oil content≤15PPm
Electric power:415V/ 50Hz /3Φ (Optional)
Motor power:0.55 kw
Method of heating: Electric heating
Outline Dimension: L×B×H=1100×690×1460 mm
Discharge pressure: 0.05-0.1Mpa
Protection grade: Electric Motor IP 44
Electric control box IP 44
Electric cable: For marine use
Outer joint flange standard: GIS standard
Surface color of the equipment: dark grey
Nameplate :Stainless steel, white characters on black background

A whole set of YWC-0.50 Type oily water separator, and each contains the following parts

No.	Name	Model	Quantity
1	1^stStage Coalescer	322DF-1-01	1 set
2	2^nd Stage Filter	322DF-1-02	2sets
3	3^rd Stage Membrane	322DF-1-03	4sets
4	Electric Box	322DF-1-00SY	1 set
5	15ppm bilge alarm		1 set
6	Marine motor		1 set
7	pump		1 set
8	Pneumatic Valve		7 sets
9	Flow meter		1 set
10	Dosing Pump		1 set
11	Safety valve		1 set
12	Pressure Meter		3 sets
13	Thermometer		1 set
14	Pressure Meter		1 set
15	Relative Pipe System		1 set
16	Trouble alarm delay

Spare Parts

No.	Name	Model	Quantity	Note
1	Spare parts of the pump		1 set
2	The 2^nd filter core	322DF-1-02	1 sets
3	O-Ring of the 1^st coalescer	DFY-1001	1 piece
4	O-Ring of the 2^nd filter	DFY-1002	1 piece
5	O-Ring of the flange	DFY-1003	8 piece
6	The seawater filter		1 piece
