Crane Used Steel Wire Rope

Introduction:

We are mainly focus on producing wire rope with large diameter, super length, high tension and special construction. Diameter ranges from 0.18mm to 260mm in a variety of ropes of point contact, line contact and surface contact. The tensile strength can reach Grade 2160 or EEIPS.

There are all kinds of wire drawings, twisting equipmets and morden assembly line can enable pre-tension, heat treatment hot-dip galvanizing for ropes in different diameters. We can produce various of steel wire rope according to our national standards such as GB8919, GB/T20118, GB/T20067 and also international standards ISO, ASTM, EN, JIS and API etc. Got API, DNV, LR, BV, CCS, MA and KA certification,which assure good quality control.

1X61 Round Strand Wire Rope:

Rope type:Slngle strand wire rope
Rope Construction：1×61

Specification：

Nominal Diameter(mm)	Approx.Weight	Nominal Tensile Strength of Rope(Mpa)
	Approx.Weight	1570	1670	1770	1870	1960
	kg/100m	Minimun Breaking Load of Rope(KN)
14	100	126	134	142	150	1580
16	131	165	175	186	196	206
18	165	209	222	235	248	260
20	204	257	274	290	307	321
22	247	312	331	351	371	389
24	294	371	394	418	442	463
26	345	435	463	491	518	543
28	400	505	537	569	601	630
30	459	579	616	653	690	720
32	522	659	701	740	790	820
34	590	740	790	840	890	930
36	661	830	890	940	990	1040
38	736	930	990	1050	1110	1160
40	816	1030	1100	1160	1230	1290
42	900	1140	1210	1280	1350	1420
44	987	1250	1330	1400	1480	1560
46	1080	1360	1450	1540	1620	1700
48	1180	1480	1580	1670	1770	1850
50	1280	1610	1710	1810	1920	2010
52	1380	1740	1850	1960	2070	2170
54	1490	1880	2000	2120	2240	2340
56	1600	2020	2150	2280	2400	2520
58	1720	2170	2300	2440	2580	2700
60	1840	2320	2460	2610	2760	2890

Note:Minimum aggregate breaking strength = Minimum breaking strength×1.198。
