Marine Pressure Gauge

[Search Related Products]

Marine Pressure Gauge


Marine Pressure Gauge

1. Suitable Medium: Gas, Liquid etc.

2. Measuring Range: 0-60 Mpa

3. Accuracy: 2.5 Grade

4. Dial Diameter: 60 mm, 75mm, 100mm, 150mm, 200mm

5. Material: Iron Alloy, Al-Alloy, Copper Alloy, Stainless Steel

Marine Pressure Gauge Mounting Dimension

D

D1

A

B

d2

d0

d1

60

ŽÁ85

64

48

ŽÁ4.5

72

ŽÁ5

75

ŽÁ98

-

-

-

88

ŽÁ4.5

100

ŽÁ130

102

80

ŽÁ5.5

118

ŽÁ6

150

ŽÁ180

-

-

-

165

ŽÁ6

200

ŽÁ230

-

-

-

215

ŽÁ6

Marine Pressure Gauge Connection Screw Thread Dimension

Dial Nominal Diameter mm

Connection Size

d

L mm

d1 mm

60

M10X1

10

ŽÁ4.5

75

M14X1.5

14

ŽÁ5

100

G3/8 inch

16

150

M20X1.5 G1/2 inch

20

ŽÁ6

200

Remark: We can produce according to customer's requirements.

6. Drawing of marine pressure gauge:

Marine Pressure Gauge

7. Certificate Available:

Marine Pressure Gauge
