Float Level Switch

Float Level Switch

1. Field: Ship Building, Ship Repair

2. Application: It is widely used in ship to control and alarm the liquid level in tank.

3. Installation: Top Mounting (Vertical Mounting)

4. Max. Working Pressure: 10 kg/cm2

5. Max. Working Temperature: 150 íŠ

6. Switch Type: Micro Switch

7. Protection: IP 56, Weather Proof

8. Size:

Nominal Pressure Size O.D P.C.D No. of Hole Diameter of Hole
5 K 65 mm 155 mm 130 mm 4 Pieces 15 mm
9. Parts Name:

No. Description
1 Body
2 Cover
3 Flange
4 Float
5 Magnet
6 Swith Box
7 Name Plate
8 Cable Gland
9 Earth Terminal
10. Drawing:

Float Level Switch
