CGY-165 Vertical Marine Projection Compass

CGY-165 Vertical Marine Projection Compass

CGY-165 Vertical Marine Projection Compass is ideal for various kinds of large and medium sized merchant and navel service vessels to indicate the heading and determine the azimuth. With an excellent optical projection system, the operator can easily and precisely observe the ship¡¯s heading in wheelhouse. This compass is mounted on the compass desk, so it efficiently saves space of wheelhouse. If you want to know more specific information, please email us.

Specifications

Project

Data

Dial Diameter

165mm

Dial Graduation

0¡ã~360¡ã, 1¡ã for each grid

Direction Error

¨Q0.5¡ã

Friction Error

¨Q0.1¡ã

Swing Semi-Period

>9.3s (20¡æ, H=30µT)

Semicircular Deviation Correction

>45¡ã (H=30µT)

Quadrant Deviation Correction

>10¡ã(H=30µT)

Heeling Error Correction

-75~ +75µT

Operation Temperature

-30¡ãC~+60¡ãC

Dial Image Expanding Rate

¡Ö2 times

Lens Barrel Flexing Range

¡À50mm

Flinder¡¯s Bar Correction

>15¡ã

Lighting Power

220V/40w 24V/40W

Outline Dimension

802¡Á485¡Á1340mm

Net Weight

¡Ö76kg

Features

1. Acting as a standard compass and a steering compass

2. With binnacle

3. Reliable performance

4. High cost performance

5. Long service life

CGY-165 Vertical Marine Projection Compass

CGY-165 Vertical Marine Projection Compass

Model :CGY-165
