Straight Snap Hook with Safety Screw

[Search Related Products]

Straight Snap Hook with Safety Screw

Straight Snap Hook with Safety Screw

Straight snap hook with safety screw is made by high carbon steel. And the size of it is from 5*50mm to 11*120mm. It could be widely used in camping equipment, equipments for fitness centers and playgrounds. Besides that, Special specification and marks can be made according to customers requirement.

Product details:

1. Item: Straight snap hook with safety screw

2. Material: high carbon steel, stainless steel

3. Technology: drop forged

4. Surface: hot dip galvanized, zinc plated, polished

5. Size: 5*50mm-11*120mm

6. Usage: lifting industry

7. Breaking load: 4 times of working load

8. Special specifications and marks can be made according to customers requirement

Specification

Size

A

C

D

L

W.L.L

N.W.

mm

mm

mm

mm

mm

lbs

kg/100pcs

5*50

25

9

5

50

220

1.8

6*60

30

11

6

60

260

2.62

8*80

40

13

8

80

500

6.5

10*100

50

16

10

100

770

14.8

11*120

58

21

11

120

990

20.5

Straight Snap Hook with Safety Screw

Sketch of the straight snap hook with screw

Straight Snap Hook with Safety Screw

Straight Snap Hook with Safety Screw

Straight snap hook with safety screw
