Home Crane Parts Sheet Piling Hammer

Sheet Piling Hammer[Search Related Products]

Sheet Piling Hammer

Sheet Piling Hammer£º

Application:

Applicabie for various models of excavators,YZC Sheet Piling Hammer can be used for steel pile,concrete pile,rail pile,iron plate,H board,band drain.Suitable for engineering construction of flood control, dam and dike,pipe rack,earthwork,retaining wall and slope.

Features:

1.Adopt original motor imported from U.S.A to drive,with small volume and light weight,can stably output high rotation speed power,strong and durable.
2.Add shock absorber,With Swedish column bearing,low noise,high speed and reliable.
3.Safety device make the clamping chuck tighten automatically while the sheet pile not loosen,safe and efficient.
4.Driven by hydraulic system,can operate with rotation of 180 degrees left and right,speed and vibration frequency can mrrt with requirements under different working conditions.

Technical Parameters£º
Model Eccentric Moment (Kg/m) Maximum Centrifugal Force(KN) Maximum Frequency (rpm) Excursion (mm) Power of Pile Extracting(KN)
YZC250 6 418 2500 20.3 128
YZC350 7.8 503 2500 21.5 140
Hydraulic power (KW) Maximum Working Pressure (bar) Working Flow Rate (L/min) Weig of Dacit Arm (Kg) Weig of Sheet Piling Hammer (kg) Total Weight (kg) Machine Ton Ton (Ton)
80-98 32 150-200 430 1452 1882 20-29
83-100 32 160-230 510 1610 2120 30-40
