Marine Diesel Generator Set[Search Related Products]
Marine Diesel Generator Set: (If you wanted other type od diesel generator, please click here.)
Chongqing Hi-sea Marine Equipment Import & Export Co., Ltd. located in the largest industrial city - Chongqing, China. We are the earliest professional manufacturer and exporter of Generator. Our company belongs to a productive factory's foreign trade department, owns advanced mechanical processing, assembling, mechanical, electrical, high-tech testing platform for 3KW-2000KW, and various microcomputer integrated test equipments. We have better service, lower price. We mainly supply gensets for telecommunication, electric power, ships, railway oil fields, express way and so on.
Main of Hi-sea Marine Generator Set is Cummins Series, Deutz Series, Volvo Series and so on. Power range is from 3KW - 2000KW, Which cover varied types for general and special users, including open type, soundproof type, trail type, containerized type and tower light, etc.
Our company has successfully passed ISO9001-2000 international quality system certification, China classification society (CCS shipping certificate) export goods license and the ministry of information industry licenses for etc. Rely on high quality product and the first-class service, the company has gradually recognized by the market, and has a huge customer base and good reputation.
We hope to cooperate with you and creat a brilliant career.
Specification
Marine Diesel Generator Set
1)3P4W,50/60HZ,water cooled
2)1500/1800rpm
3)8 hrs base fuel tank,100% load test
4)CE 1Year warranty
Technical Data
| marine diesel generator Set | |
| Genset model | HS |
| Type | open or sound-proof&weather-proof |
| Genset output power range | 8kw-1500kw |
| Rated voltage | 400/230V, 380/220V,415/240V,240/120V |
| Frequency | 50 or 60HZ |
| Power factor | 0.8 lagging |
| Rated speed | 1500 or 1800rpm |
| Output type | AC Three phase or single phase |
| Motor | brushless alternator |
| Frequency | <3% |
| Frequency at stable state | <0.5% |
| Frequency devitation at instantaneous state | ¡Ü+10% |
| Frequency return time | ¡Ü3 S |
| Voltage devitation at stable state | ¡Ü+ - 1% |
| Voltage devitation at instantaneous state | ¡Ü+20% |
| Voltage reture time | ¡Ü4 S |
| Voltage modulation | ¡Ü0.3% |
| The specifications of engine: | |
| Model |
4B3.9-G,4BT3.9-G,4BTA3.9-G,6BT5.9-G,6BTA5.9-G,6BTAA5.9-G,6CTAA8.3-G,6LTAA8.9-G, NTA855-G,KTA19-G,KTAA19-G,KT38-G,KTA38-G |
| Cooling method | water cooled |
| Rated speed | 1500 or 1800rmp |
| Governor system | Electrical or mechanical governor |
| Aspiration mode | Natural asprirated or turbocharged |
| Starting method | 12/24V DC electric starting |
| Stoke | 4 stoke |
| The specifications of alternator: | |
| Brand | Cummins, Stamford,Leroy semor, Marathon etc. |
| Regulator | AVR automatic voltage regulating |
| Excite type | pret or shunt |
| Connecting type | 3PH start, 3PH delta |
| Steady frequency change | 0-5% |
| No load voltage | great than or equal to 95%-105 |
| Steady voltage | ¡Ü+- 1 |
| Insulation degree | H degree |
| Exclosure degree | IP23 |
| Other specifications of generator set: | |
| 1. Control system | |
| 1) Automatic alarm system : the unit has the acousto-optics alarm system and arrestor for any situation as the start defeat. | the water is over temperature, the oil pulls down, over speed, over load and over current. |
| 2)operation display | |
| a)unit votage, tri-phase load current and frequency display | |
| b)water temperature,oil pressure display | |
| c)fuel level, fuel temperature display | |
| d)audible and visual alarm lamps and buzzers | |
| 2. Starting system: DC alternator is used to start the engine | |
| 3. Short circuit protection: MCCB air switch | |
| 4. cooling sytem: combined cooling watertank fitted to meet the requirements of radiation at ambient temperature 40 centigrade | |
| 5. Filter system: oil ,fuel, and air filter | |
| 6. Accessories: exhaust elbow,muffler, | |
| 7. Supply standard collocation: | |
| a) diesel engine with all accessories,3 filter,electric systems | |
| b)alternator | |
| c)steel structure | |
| d)fan and water tank cooling system | |
| e)flange connector | |
| f)12/24V starting motor and charge engine | |
| g) air cleaner, fuel cleaner, oil clearner | |
| h) on-board control panel | |
| i) MCCB air conservation switch | |
| j)12/24V starting accumulator and battery lines | |
| k)set shock absorber | |
| l)high - efficient silencer | |
| Packing: | Wooden cases |
