Marine Diesel Generator[Search Related Products]
Marine Diesel Generator: (If you wanted other type of diesel generator, please click here.)
Chongqing Hi-sea Marine Equipment Import & Export Co., Ltd. located in the largest industrial city - Chongqing, China. We are the earliest professional manufacturer and exporter of Generator. Our company belongs to a productive factory's foreign trade department, owns advanced mechanical processing, assembling, mechanical, electrical, high-tech testing platform for 3KW-2000KW, and various microcomputer integrated test equipments. We have better service, lower price. We mainly supply gensets for telecommunication, electric power, ships, railway oil fields, express way and so on.
Main of Hi-sea Marine Generator Set is Cummins Series, Deutz Series, Volvo Series and so on. Power range is from 3KW - 2000KW, Which cover varied types for general and special users, including open type, soundproof type, trail type, containerized type and tower light, etc.
Our company has successfully passed ISO9001-2000 international quality system certification, China classification society (CCS shipping certificate) export goods license and the ministry of information industry licenses for etc. Rely on high quality product and the first-class service, the company has gradually recognized by the market, and has a huge customer base and good reputation.
We hope to cooperate with you and creat a brilliant career.
Specification
Marine Diesel Generator
1.cummins marine generator set, from 20-1000kw
2.marine class approved.
3.Both cummins emergency and main marine genset.
4.Engine: cummins marine generator Powered by Cummins Engine 30-1000kW marine generator sets which adopts cummins series marine diesel engine(CCS Certificate)
5.Alternator: Equipped with some famous brushless excitation alternators. (Marathon, Stamford, etc. ) a Provided CCS certificate
6.Cooling system for cummins marine generator(emergency or main power): Fan and radiator cooling or heat exchanger cooling
Main function: It can dispaly water/oil temperature, oil pressure, battery voltage, speed and running time, , and also has stop/start function, self -diagona, reset, and emmergency stop. Can also indicate running by lamp and low oil pressure pre-alarm, low oil pressure stop, high tempreture pre-alarm, high-tempreture stop, high oil temperature, bettery power shorttage indication, over speed stop. Has the passive alarm contact of run, low oil pressure pre-alarm, low oil pressure stop, high water temperature stop, high oil temperature, over speed stop and so on. This control system can meet the requried of the Shipping inspection.
Technical Data
| Power (KW) | Brake horse power HP | Speed (RPM) | Engine Model | Rated |
| 164 | 220 | 1800 | NT855-M | CON |
| 179 | 240 | 1800 | NT855-M | CON |
| 201 | 270 | 1800 | NT855-M | CON |
| 224 | 300 | 1800 | NT855-M | CON |
| 261 | 350 | 1800 | NTA855-M | CON |
| 269 | 360 | 2100 | NTA855-M | MCD |
| 298 | 400 | 2100 | NTA855-M | MCD |
| 317 | 425 | 1800 | KT19-M | CON |
| 351 | 470 | 1800 | KTA19-M | CON |
| 373 | 500 | 1800 | KTA19-M3 | CON |
| 410 | 550 | 2100 | KTA19-M3 | HD |
| 447 | 600 | 1800 | KTA19-M3 | CON |
| 477 | 640 | 1800 | KTA19-M3 | HD |
| 522 | 700 | 2100 | KTA19-M4 | MCD |
| 597 | 800 | 1800 | KTA38-M | CON |
| 671 | 800 | 1800 | KTA39-M0 | CON |
| 746 | 1000 | 1800 | KTA39-M1 | CON |
| 895 | 1200 | 1800 | KTA39-M2 | CON |
| 186 | 250 | 1800 | NT855-M | CON |
| 209 | 280 | 1800 | NT855-M | CON |
| 298 | 400 | 1800 | NTA855-M | CON |
| 336 | 450 | 1800 | NTA855-M | CON |
| Power KW/ Brake horse power | Max Power KW (Brake horse power ) | Speed(RPM) | Engine Model | Rated power |
| 240(322) | 265(355) | 1500 | NTA855-DM | 210KW |
| 283(380) | 321(430) | 1500 | NTA855-DM | 250KW |
| 287(385) | 317(425) | 1800 | NTA855-DM | 240KW |
| 313(420) | 347(465) | 1800 | NTA855-DM | 330KW |
| 317(425) | 351(371) | 1500 | NTA855-DM | 280KW |
| 336(450) | 369(495) | 1500 | KTA19-DM | 300KW |
| 403(540) | 448(600) | 1500 | KTA19-DM | 350KW |
| 447(600) | 504(675) | 1500 | KTA19-DM | 400KW |
| 463(620) | 511(685) | 1800 | KTA19-DM | 425KW |
| 507(563) | 563(755) | 1800 | KTA19-DM | 470KW |
| 180(241) | 198(265) | 1500 | NTA855-DM | 160KW |
| 231(310) | 254(340) | 1500 | NTA855-DM | 200KW |
| 264(354) | 291(390) | 1500 | NTA855-DM | 240KW |
| 312(418) | 343(460) | 1500 | NTA855-DM | 280KW |
| 392(525) | 448(600) | 1800 | KTA19-DM | 360KW |
| 560(750) | 615(825) | 1500 | KT38-DM | 510KW |
| 679(910) | 747(1000) | 1800 | KTA38-DM | 620KW |
| 664(890) | 731(980) | 1500 | KTA38-DM | 600KW |
| 809(1085) | 895(1200) | 1800 | KTA38-DM | 720KW |
| 813(1090) | 895(1200) | 1500 | KTA38-DM | 720KW |
| 1007(1350) | 1120(1490) | 1800 | KTA38-DM | 900KW |
| 880(1180) | 970(1300) | 1500 | KTA38-DM | 800KW |
