Gasoline Engine Cultivator
[Search Related Products]
Multifunctional Farming Machinery:
| Model | HS-76 | HS-80 | HS-100 | HS-750 |
| Engine model | SR170F/P | SR170F/P | SR170F/P | SR170F/P |
| Engine type | OHV 25°Single cylinder, forced air cooling, 4-stroke | OHV 25°Single cylinder, forced air cooling, 4-stroke | OHV 25°Single cylinder, forced air cooling, 4-stroke | OHV 25°Single cylinder, forced air cooling, 4-stroke |
| Bore *stroke(mm) | 70*54 | 70*54 | 70*54 | 70*54 |
| Starting system | Recoil start | Recoil start | Recoil start | Recoil start |
| Rated output(kW) | 4.2 | 4.2 | 4.2 | 4.2 |
| Rated rotary speed(r/min) | 3600 | 3600 | 3600 | 3600 |
| Tilling depth(cm) | ≥10 | ≥10 | ≥10 | ≥10 |
| Tilling scope(cm) | 90 | 80 | 100 | 75 |
| Working speed(m/s) | 0.1~0.3 | 0.14 | 0.1~0.3 | 0.14 |
| Working performance(hm2/h.m) | ≥0.02 | ≥0.04 | ≥0.04 | ≥0.04 |
| Fuel consumption(kg/hm2) | ≤40 | ≤30 | ≤30 | ≤30 |
| Driving Mode | Straight tooth transmission | Belt transmission | Gear driving | Belt transmission |
| Connection mode | Straight | V-belt connection | Straight | V-belt connection |
| Designing rotary speed(r/min) | Slow 95; Fast 130 | Slow 102; Fast 135 | Slow 65; Fast 113 | Slow 90; Fast 129 |
| Max Radius of gyration(mm) | 165 | 165 | 180 | 165 |
| Amount of blades | 18 | 24 | 28 | 24 |
| The model of rotary blade | No. 2 blade | No. 2 blade | No. 2 blade | No. 2 blade |
| Tiller size (mm) | 1350*700*700 | 1550*900*910 | 1700*1000*800 | 1550*900*910 |
| Package dimensions(mm) | 190*570*800 | 880*490*780 | 850*570*755 | 810*375*735 |
| Loading quantity(20/40/40HQ) | 66/138/138 | 84/183/183 | 78/168/168 | 124/258/264 |
| N.W(kg) | 65 | 80 | 87.5 | 72.4 |
