Home Bearings Cylindrical roller bearing Large Double row full complement cylindrical roller bearings

Double row full complement cylindrical roller bearings NNF[Search Related Products]

Double row full complement cylindrical roller bearings NNF

Double row full complement cylindrical roller bearings:

1.Suitable for very heavy radial loads, low speed application,

2.Non-separable, with an annular groove and three lubrication holes to facilitate efficient lubrication.

NCF Series:

I.D. O.D. width
(mm) 		WIGHT(KG) BEARING CODE I.D. O.D. width
(mm) 		WIGHT(KG) BEARING CODE I.D. O.D. width
(mm) 		WIGHT(KG) BEARING CODE
220 300 48 9,90 NCF 2944 CV 400 500 46 20,5 NCF 1880 V 600 730 60 51,5 NCF 18/600 V
220 340 90 29,5 NCF 3044 CV 400 540 82 54,5 NCF 2980 CV 600 730 78 67,5 NCF 28/600 V
220 400 108 58,0 NCF 2244 V 400 600 148 145 NCF 3080 CV 600 800 118 170 NCF 29/600 V
220 460 145 111 NJG 2344 VH 420 520 46 21,0 NCF 1884 V 630 780 69 72,5 NCF 18/630 V
240 300 28 4,40 NCF 1848 V 420 560 82 57,0 NCF 2984 CV 630 780 88 92,5 NCF 28/630 V
240 320 48 10,6 NCF 2948 CV 420 620 150 150 NCF 3084 CV 630 850 128 205 NCF 29/630 V
240 360 92 32,0 NCF 3048 CV 440 540 46 22,0 NCF 1888 V 670 820 69 76,5 NCF 18/670 V
240 500 155 147 NJG 2348 VH 440 540 60 29,0 NCF 2888 V 670 820 88 97,5 NCF 28/670 V
260 320 28 4,75 NCF 1852 V 440 600 95 80,5 NCF 2988 V 670 900 136 245 NCF 29/670 V
260 360 60 18,5 NCF 2952 CV 440 650 157 175 NCF 3088 CV 710 870 74 92,5 NCF 18/710 V
260 400 104 46,5 NCF 3052 CV 460 580 56 34,0 NCF 1892 V 710 870 95 115 NCF 28/710 V
260 540 165 177 NJG 2352 VH 460 580 72 44,0 NCF 2892 V 710 950 140 275 NCF 29/710 V
280 350 33 7,10 NCF 1856 V 460 620 95 83,5 NCF 2992 V 750 920 78 110 NCF 18/750 V
280 380 60 19,7 NCF 2956 CV 460 680 163 195 NCF 3092 CV 750 920 100 140 NCF 28/750 V
280 420 106 50,0 NCF 3056 CV 480 600 56 35,5 NCF 1896 V 750 1000 145 315 NCF 29/750 V
300 380 38 10,0 NCF 1860 V 480 600 72 46,0 NCF 2896 V 800 980 82 130 NCF 18/800 V
300 420 72 31,2 NCF 2960 CV 480 650 100 98,0 NCF 2996 V 800 980 106 165 NCF 28/800 V
300 460 118 69,0 NCF 3060 CV 480 700 165 205 NCF 3096 CV 800 1060 150 360 NCF 29/800 V
320 400 38 10,5 NCF 1864 V 500 620 56 36,5 NCF 18/500 V 850 1030 82 135 NCF 18/850 V
320 440 72 32,9 NCF 2964 CV 500 620 72 48,0 NCF 28/500 V 850 1030 106 175 NCF 28/850 V
320 480 121 74,5 NCF 3064 CV 500 670 100 100 NCF 29/500 V 850 1120 155 405 NCF 29/850 V
340 420 38 11,0 NCF 1868 V 500 720 167 215 NCF 30/500 CV 900 1090 85 160 NCF 18/900 V
340 460 72 35,0 NCF 2968 CV 530 650 56 38,5 NCF 18/530 V 900 1090 112 208 NCF 28/900 V
340 520 133 100 NCF 3068 CV 530 650 72 49,5 NCF 28/530 V 900 1180 165 472 NCF 29/900 V
360 440 38 11,5 NCF 1872 V 530 710 106 120 NCF 29/530 V 950 1150 90 185 NCF 18/950 V
360 480 72 36,5 NCF 2972 CV 530 780 185 300 NCF 30/530 V 950 1150 118 240 NCF 28/950 V
360 540 134 105 NCF 3072 CV 560 680 56 40,5 NCF 18/560 V 950 1250 175 565 NCF 29/950 V
380 480 46 19,5 NCF 1876 V 560 680 72 54,0 NCF 28/560 V 1000 1220 100 230 NCF 18/1000 V
380 520 82 52,5 NCF 2976 CV 560 750 112 140 NCF 29/560 V 1000 1220 128 310 NCF 28/1000 V
380 560 135 110 NCF 3076 CV 560 820 195 345 NCF 30/560 V 1000 1320 185 680 NCF 29/1000 V
400 500 46 20,5 NCF 1880 V 400 500 46 20,5 NCF 1880 V 1120 1360 106 298 NCF 18/1120 V
400 540 82 54,5 NCF 2980 CV 400 540 82 54,5 NCF 2980 CV

SL Series:

new code old code I.D. O.D. width
(mm) 		weight new code old code I.D. O.D. width
(mm) 		weight
(mm) (mm) (kg) (mm) (mm) (kg)
SL014876 - 380 480 100 44.2 NNF5026 SL045026PP 130 200 90 10.5
SL014830 SL014830 150 190 40 2.9KG NNF130 SL04130PP 130 190 80 7.5
SL014832 SL014832 160 200 40 3.1kg NNF140 SL04140PP 140 200 80 8
SL014834 SL014834 170 215 45 4.1KG SL045034PP - 170 260 122 22.6
SL014836 SL014836 180 225 45 4.3KG NNF5022NR SL045022ADA-2LSV 110 170 80 6.57
SL014838 SL014838 190 240 50 5.65KG SL04130-PP SL04 130 PP 130 190 80 7.5kg
SL014840 SL014840 200 250 50 5.9KG SL04140-PP SL04 140 PP 140 200 80 8kg
SL014844 SL014844 220 270 50 6.4KG SL04150-PP SL04 150 PP 150 210 80 8.4kg
SL014848 SL014848 240 300 60 10KG SL04160-PP SL04 160 PP 160 220 80 8.8kg
SL014852 SL014852 260 320 60 11KG SL04170-PP SL04 170 PP 170 230 80 9.3kg
SL014856 SL014856 280 350 69 16KG SL04180-PP SL04 180 PP 180 240 80 9.8kg
SL014860 SL014860 300 380 80 23KG SL04190-PP SL04 190 PP 190 260 80 12.7kg
SL014860 SL014860 300 380 80 23kg SL04200-PP SL04 200 PP 200 270 80 13.2kg
SL014864 SL014864 320 400 80 24kg SL04220-PP SL04 220 PP 220 300 95 19.5kg
SL014868 SL014868 340 420 80 25.5kg SL04240-PP SL04 240 PP 240 320 95 21kg
SL014872 SL014872 360 440 80 27kg SL04260-PP SL04 260 PP 260 340 95 22.5kg
SL014880 SL014880 400 500 100 46.5kg SL04300-PP SL04 300 PP 300 380 95 25.5kg
SL014880 SL01 4880 400 500 100 46.5kg SL045026-PP SL04 5026 PP 130 200 95 10.5kg
SL045052NR 5372152 260 400 190 90.7 SL045028-PP SL04 5028 PP 140 210 95 11.1kg
SL045048NR 5372148 240 360 160 59.5 SL045030-PP SL04 5030 PP 150 225 100 13.3kg
SL045030NR 5372130 150 225 100 14.6 SL045032-PP SL04 5032 PP 160 240 109 16.6kg
SL045028X 5372128 140 210 94 9.337 SL045034-PP SL04 5034 PP 170 260 122 22.6kg
SL045017PP - 85 130 59 2.83 SL045034-PP SL04 5034 PP 170 260 122 22.6kg
SL045018PP - 90 140 66 3.71 SL045036-PP SL04 5036 PP 180 280 136 30.1kg
SL045019PP - 95 145 66 3.88 SL045038-PP SL04 5038 PP 190 290 136 31.5kg
SL045020PP - 100 150 66 3.95 SL045040-PP SL04 5040 PP 200 310 150 40.8kg
SL045022PP - 110 170 79 6.57 SL045044-PP SL04 5044 PP 220 340 160 52.5kg
SL045024PP - 120 180 79 7.04 SL045048-PP SL04 5048 PP 240 360 160 56kg
SL045026PP - 130 200 94 10.5 SL045052-PP SL04 5052 PP 260 400 190 84.5kg
SL045030PP - 130 190 79 7.5 SL045056-PP SL04 5056 PP 280 420 190 90kg
SL045009PP - 45 75 39 0.7 SL045060-PP SL04 5060 PP 300 460 218 126kg
SL045009PP - 40 70 40 0.7 SL024876/P6 - 380 480 100 43.7
SL045010PP - 50 80 40 0.76 SL024876 - 380 480 100 43.7
NNF5013 SL045013PP 65 100 46 1.33 SL024830 SL02 4830 150 190 40 2.8kg
NNF5014 SL045014PP 70 110 54 1.87 SL024832 SL02 4832 160 200 40 3kg
NNF5015 SL045015PP 75 115 54 1.96 SL024834 SL02 4834 170 215 45 3.95kg
NNF5016 SL045016PP 80 125 60 2.71 SL024836 SL02 4836 180 225 45 4.15kg
NNF5017 SL045017PP 85 130 60 2.87 SL014964 SL01 4964 320 440 118 56kg
NNF5024 SL045024PP 120 180 80 7.04 SL014972 SL01 4972 360 480 118 62.1kg
NNF5026 SL045026PP 130 200 90 10.5 NNF130 SL04130PP 130 190 80 7.5
SL024838 SL02 4838 190 240 50 5.45kg SL024944 SL02 4944 220 300 80 16.7kg
SL024840 SL02 4840 200 250 50 5.7kg SL024952 SL02 4952 260 360 100 31.2kg
SL024844 SL02 4844 220 270 50 6.2kg SL024956 SL02 4956 280 380 100 33.1kg
SL024848 SL02 4848 240 300 60 9.9kg SL024960 SL02 4960 300 420 118 51.9kg
SL024852 SL02 4852 260 320 60 10.6kg SL024964 SL02 4964 320 440 118 54.9kg
SL024856 SL02 4856 280 350 69 15.6kg SL024968 SL02 4968 340 460 118 57.8kg
SL024860 SL02 4860 300 380 80 22kg SL024972 SL02 4972 360 480 118 60.8kg
SL024864 SL02 4864 320 400 80 23.5kg SL024976 SL02 4976 380 520 140 90.5kg
SL024868 SL02 4868 340 420 80 25kg SL024980 SL02 4980 400 540 140 94.6kg
SL024872 SL02 4872 360 440 80 26kg SL014930 SL01 4930 150 210 60 6.65kg
SL024880 SL02 4880 400 500 100 45.8kg SL014932 SL01 4932 160 220 60 7kg
SL024948AC3 - 240 320 80 17.9 SL014934 SL01 4934 170 230 60 7.35kg
SL024948 - 240 320 80 17.9 SL014936 SL01 4936 180 250 69 10.8kg
SL024944A - 220 300 80 16 SL014938 SL01 4938 190 260 69 11.2kg
SL024930 SL02 4930 150 210 60 6.45kg SL014940 SL01 4940 200 280 80 15.8kg
SL024932 SL02 4932 160 220 60 6.8kg SL014944 SL01 4944 220 300 80 17.2kg
SL024934 SL02 4934 170 230 60 7.1kg SL014948 SL01 4948 240 320 80 18kg
SL024936 SL02 4936 180 250 69 10.5kg SL014952 SL01 4952 260 360 100 32kg
SL024938 SL02 4938 190 260 69 10.9kg SL014956 SL01 4956 280 380 100 34kg
SL024940 SL02 4940 200 280 80 15.3kg SL014960 SL01 4960 300 420 118 53kg
