Auto-darkening Welding Face Shield[Search Related Products]
EH-1 Series Welding Face Shield & ADF parameters Choose Model
|
No |
ADF Model Parameter |
EF9040J |
EF9040 |
EF9242 |
EF9646 |
EF9848 |
|
1 |
View area |
90mm*40mm |
90mm*40mm |
92mm*42mm |
96mm*46mm |
98mm*48mm |
|
2 |
Range of UV/IR Protection |
DIN 14 |
DIN 16 |
DIN 16 |
DIN 16 |
DIN 16 |
|
3 |
Light Shade |
DIN 4 |
DIN 4 |
DIN 4 |
DIN 4 |
DIN 4 |
|
4 |
Dark Shade |
DIN 7-11 |
DIN 9-13 |
DIN 9-13 |
DIN 9-13 |
DIN 9-13 |
|
5 |
Power Supply |
Solar cells,2 lithium batteries be charged, with ON/OFF switch |
||||
|
6 |
Power on/off |
Fully automatic |
||||
|
7 |
Switch time |
<0.5ms |
1/25000s |
1/25000s |
1/25000s |
1/25000s |
|
8 |
Time from dark to light |
0.6s-0.8s |
0.6s-0.8 |
0.6s-0.8 |
0.1s-1s |
0.1s-1s |
|
9 |
Sensitivity control |
Low or high |
||||
|
10 |
Operating temperature |
-5℃~+55℃ |
-5℃~+55℃ |
-10℃~+55℃ |
-10℃~+55℃ |
-10℃~+55℃ |
|
11 |
Storage temperature |
-10℃~+70℃ |
-10℃~+70℃ |
-20℃~+70℃ |
-20℃~+70℃ |
-20℃~+70℃ |
|
12 |
TIG,MIG Protective |
No |
Yes |
Yes |
Yes |
Yes |
|
13 |
Weight |
0.48kgs |
||||
|
14 |
Frame size |
340mm*240mm*220mm |
||||
|
15 |
Material |
PP or PA |
||||
|
16 |
Optional colors |
Blue, green, black, yellow, red, beautiful pictures etc. |
||||
|
17 |
Packing |
A. 4pcs/ carton, N/G Weight: 2.568/5.455kgs,size:540*534*316mm; B. 10pcs/ carton, N/G Weight: 6.42/11.5kgs, size:742*534*290mm; C. 20pcs/ carton, N/G Weight: 12.84/22.15kgs, size:742*534*440mm. |
||||
EH-2 Series Welding Face Shield & ADF parameters Choose Model
|
No |
ADF Model Parameter |
EF9040J |
EF9040 |
EF9242 |
EF9646 |
EF9848 |
|
1 |
View area |
90*40 mm |
90*40 mm |
92*42 mm |
96*46 mm |
98*48 mm |
|
2 |
Range of UV/IR Protection |
DIN 14 |
DIN 16 |
DIN 16 |
DIN 16 |
DIN 16 |
|
3 |
Light Shade |
DIN 4 |
DIN 4 |
DIN 4 |
DIN 4 |
DIN 4 |
|
4 |
Dark Shade |
DIN 7-11 |
DIN 9-13 |
DIN 9-13 |
DIN 9-13 |
DIN 9-13 |
|
5 |
Power Supply |
Solar cells, 2 lithium batteries charged, with ON/OFF switch |
||||
|
6 |
Power on/off |
Fully automatic |
||||
|
7 |
Switch time |
<0.5ms |
1/25000s |
1/25000s |
1/25000s |
1/25000s |
|
8 |
Time from dark to light |
0.6s-0.8s |
0.6s-0.8 |
0.6s-0.8 |
0.1s-1s |
0.1s-1s |
|
9 |
Sensitivity control |
Low or high |
||||
|
10 |
Operating temperature |
-5℃~+55℃ |
-5℃~+55℃ |
-10℃~+55℃ |
-10℃~+55℃ |
-10℃~+55℃ |
|
11 |
Storage temperature |
-10℃~+70℃ |
-10℃~+70℃ |
-20℃~+70℃ |
-20℃~+70℃ |
-20℃~+70℃ |
|
12 |
TIG, MIG Protective |
No |
Yes |
Yes |
Yes |
Yes |
|
13 |
Weight |
0.52kgs |
||||
|
14 |
Frame size |
360mm*240mm*220mm |
||||
|
15 |
Material |
PP or PA |
||||
|
16 |
Optional colors |
Blue, green, black, yellow, red, beautiful pictures etc. |
||||
|
17 |
Packing |
A. 4pcs/ carton, N/G Weight: 2.148/5.305kgs, size:540*534*316mm; B. 10pcs/ carton, N/G Weight: 5.37/10.45kgs, size:742*534*290mm; C. 20pcs/ carton, N/G Weight: 10.74/20.057kgs, size:750*560*440mm. |
||||
EH-3 Series Welding Face Shield parameters Choose Model
|
No |
ADF Model Parameter |
EH-3/EF9040J |
EH-3/EF9040 |
EH-3/EF9242 |
EH-3/EF9646 |
EH-3/EF9848 |
|
1 |
View area |
90*40 mm |
90*40 mm |
92*42 mm |
96*46 mm |
98*48 mm |
|
2 |
Range of UV/IR Protection |
DIN 14 |
DIN 15 |
DIN 15 |
DIN 16 |
DIN 16 |
|
3 |
Light Shade |
|
DIN 4 |
DIN 4 |
DIN 4 |
DIN 4 |
|
4 |
Dark Shade |
DIN 7-11 |
DIN 9-13 |
DIN 7-13 |
DIN 9-13 |
DIN 9-13 |
|
5 |
Power Supply |
Solar cells, 2 lithium batteries charged, with ON/OFF switch |
||||
|
6 |
Sensitivity control |
Low or high |
||||
|
7 |
Switch time |
<0.5ms |
1/20000s |
1/25000s |
1/25000s |
1/25000s |
|
8 |
Time from dark to light |
0.1s-0.6s |
0.1s-0.6s |
0.6s-0.8s |
0.1s-0.8s |
0.1s-1s |
|
9 |
Sensitivity control |
Low or high |
||||
|
10 |
Operating temperature |
-5℃~+55℃ |
-5℃~+55℃ |
-5℃~+55℃ |
-10℃~+55℃ |
-10℃~+55℃ |
|
11 |
Storage temperature |
-10℃~+70℃ |
-10℃~+70℃ |
-20℃~+70℃ |
-20℃~+70℃ |
-20℃~+70℃ |
|
12 |
TIG,MIG Protective |
No |
No |
No |
Yes |
Yes |
|
13 |
Weight |
0.512 kgs |
||||
|
14 |
Frame size |
345mm*230mm*210mm |
||||
|
15 |
Material |
PP or PA |
||||
|
16 |
Optional colors |
Blue, green, black, yellow, red etc. |
||||
|
17 |
Packing |
A. 4pcs/ carton, N/G Weight: 2.148/5.035kgs, size:540*534*316mm; B. 10pcs/ carton, N/G Weight: 5.37/10.45kgs, size:742*534*290mm; C. 20pcs/ carton, N/G Weight: 10.74/20.057kgs, size:750*560*440mm. |
||||
EH-4 Series Welding Face Shield & ADF parameters Choose Model
|
No |
ADF Model Parameter |
EF9040J |
EF9040 |
EF9242 |
EF9646 |
EF9848 |
|
1 |
View area |
90*40 mm |
90*40 mm |
92*42 mm |
96*46 mm |
98*48 mm |
|
2 |
Range of UV/IR Protection |
DIN 14 |
DIN 16 |
DIN 16 |
DIN 16 |
DIN 16 |
|
3 |
Light Shade |
DIN 4 |
DIN 4 |
DIN 4 |
DIN 4 |
DIN 4 |
|
4 |
Dark Shade |
DIN 7-11 |
DIN 9-13 |
DIN 9-13 |
DIN 9-13 |
DIN 9-13 |
|
5 |
Power Supply |
Solar cells, 2 lithium batteries charged, with ON/OFF switch |
||||
|
6 |
Power on/off |
Fully automatic |
||||
|
7 |
Switch time |
<0.5ms |
1/25000s |
1/25000s |
1/25000s |
1/25000s |
|
8 |
Time from dark to light |
0.6s-0.8s |
0.6s-0.8s |
0.6s-0.8s |
0.1s-1s |
0.1s-1s |
|
9 |
Sensitivity control |
Low or high |
||||
|
10 |
Operating temperature |
-5℃~+55℃ |
-5℃~+55℃ |
-10℃~+55℃ |
-10℃~+55℃ |
-10℃~+55℃ |
|
11 |
Storage temperature |
-10℃~+70℃ |
-10℃~+70℃ |
-20℃~+70℃ |
-20℃~+70℃ |
-20℃~+70℃ |
|
12 |
TIG,MIG Protective |
Yes |
Yes |
Yes |
Yes |
Yes |
|
13 |
Weight |
0.518kgs |
||||
|
14 |
Frame size |
350mm*250mm*220mm |
||||
|
15 |
Material |
PP or PA |
||||
|
16 |
Optional colors |
Blue, green, black, yellow, red, beautiful pictures etc. |
||||
|
17 |
Packing |
A. 4pcs/ carton, N/G Weight: 2.256/5.143kgs, size:540*534*316mm; B. 10pcs/ carton, N/G Weight: 5.64/10.72kgs, size:742*534*290mm; C. 20pcs/ carton, N/G Weight: 11.28/20.597kgs, size:742*534*440mm. |
||||
