7HP Gasoline Engine Mini Tiller
[Search Related Products]
| Model | HS-100 |
| Engine model | SR170F/P |
| Engine type | OHV 25°Single cylinder, forced air cooling, 4-stroke |
| Bore *stroke(mm) | 70*54 |
| Starting system | Recoil start |
| Rated output(kW) | 4.2 |
| Rated rotary speed(r/min) | 3600 |
| Tilling depth(cm) | ≥10 |
| Tilling scope(cm) | 100 |
| Working speed(m/s) | 0.1~0.3 |
| Working performance(hm2/h.m) | ≥0.04 |
| Fuel consumption(kg/hm2) | ≤30 |
| Driving Mode | Gear driving |
| Connection mode | Straight |
| Designing rotary speed(r/min) | Slow 65; Fast 113 |
| Max Radius of gyration(mm) | 180 |
| Amount of blades | 28 |
| The model of rotary blade | No. 2 blade |
| Tiller size (mm) | 1700*1000*800 |
| Package dimensions(mm) | 850*570*755 |
| Loading quantity(20/40/40HQ) | 78/168/168 |
| N.W(kg) | 87.5 |
