5.5HP Gasoline Engine Mini Rotary Cultivator
[Search Related Products]
| Model | SR1Z-550 |
| Engine model | SR1P64F/P |
| Engine type | OHV 25°Single cylinder, forced air cooling, 4-stroke |
| Bore *stroke(mm) | 64*42 |
| Starting system | Recoil start |
| Rated output(kW) | 2.1 |
| Rated rotary speed(r/min) | 3600 |
| Tilling depth(cm) | ≥10 |
| Tilling scope(cm) | 55 |
| Working speed(m/s) | 0.1~0.3 |
| Working performance(hm2/h.m) | ≥0.02 |
| Fuel consumption(kg/hm2) | ≤40 |
| Driving Mode | Gear transmission |
| Connection mode | Straight |
| Designing rotary speed(r/min) | 112 |
| Max Radius of gyration(mm) | 150 |
| Amount of blades | 16 |
| The model of rotary blade | No. 2 blade |
| Tiller size (mm) | 1200*550*800 |
| Package dimensions(mm) | 720*385*590 |
| Loading quantity(20/40/40HQ) | 192/384/384 |
| N.W(kg) | 35 |
