137 Steel Strand Wire Rope
Introduction:
We are mainly focus on producing wire rope with large diameter, super length, high tension and special construction. Diameter ranges from 0.18mm to 260mm in a variety of ropes of point contact, line contact and surface contact. The tensile strength can reach Grade 2160 or EEIPS.
There are all kinds of wire drawings, twisting equipmets and morden assembly line can enable pre-tension, heat treatment hot-dip galvanizing for ropes in different diameters. We can produce various of steel wire rope according to our national standards such as GB8919, GB/T20118, GB/T20067 and also international standards ISO, ASTM, EN, JIS and API etc. Got API, DNV, LR, BV, CCS, MA and KA certification,which assure good quality control.


137 Steel Strand Wire Rope


1X37 Round Strand Wire Rope:

  • Rope type:Slngle strand wire rope
  • Rope Construction137

  • Rope Diameter (mm) Approx Weight (kg/100m) Tensile Strength (Mpa)
    1570 1670 1770 1870
    Minimum Breaking Strength (kN)
    4.2 8.84 13.6 14.4 15.3 16.2
    4.9 12 18.5 19.6 20.8 22
    5.6 15.7 24.1 25.7 27.2 28.7
    6.3 19.9 30.5 32.5 34.4 36.4
    7 24.5 37.7 40.1 42.5 44.9
    7.7 29.7 45.6 48.5 51.4 54.3
    8.4 35.4 54.3 57.7 61.2 64.7
    9.1 41.5 63.7 67.8 71.8 75.9
    9.8 48.1 73.9 78.6 83.3 88
    10.5 55.2 84.8 90.2 95.6 101
    11 60.6 93.1 99 105 111
    12 72.1 111 118 125 132
    12.5 78.3 120 128 136 143
    14 98.2 151 160 170 180
    15.5 120 185 197 208 220
    17 145 222 236 251 265
    18 162 249 265 281 297
    19.5 191 292 311 330 348
    21 221 339 361 382 404
    22.5 254 389 414 439 464

    Note:Minimum aggregate breaking strength = Minimum breaking strength1.176

    137 Steel Strand Wire Rope

    1*37 Steel Strand Wire Rope

    137 Steel Strand Wire Rope
